Product Description
The 2025 edition of the CM 730 is a cost effective printer with a large, high-res color touchscreen. It is reliable in tough conditions, ensures quality prints, and is easy to set up and use with a clear 10 inch display.
- Reliability of operation in the harshest environments. Quality of printing monitored and maintained to deliver perfect code every print.
- Cost Saving features of single part service and solvent consumption saving system. The CM730 has it all covered.
- A quick change, combined, separate filter unit with up to 2 years life
- A modular well protected IP55 industrial structure
- Up to 4 lines of high quality print
Specifications：
| Dots | 25 Dots Matrix |
| Nozzle size | 60um/70um Optional |
| Print height | 1.5-12 mm |
| Print distance | 8 mm best |
| Print line | 1-4 Lines |
| Print speed |
1 Line 5*5: 320m/min 1 Lines 7*7: 240m/min 2 Lines 7*16: 60m/min 3 Lines 7*25: 25m/min |
| Print content | Text, Code128, Code39, EAN128, EAN13, EAN8, Data-Matrix, QR Code, UPC-A, Logo, Date, Time, Counter, Shiftcode |
| Languages | English, Simplified Chinese, Traditional Chinese, French, Portuguese, German, Swedish, Vietnamese, Turkish, Korean, Spanish, Arabic, Romanian, Russian, Polish, Greek, Thai, Czech, Norwegian, Croatian, Italian, Hungarian |
| Printhead umbilical | Very flexible, 3m (optional 6 m) |
| Custom logo/graphics | USB to load logos and backup/restore |
| Fluids containers | 750ml Ink / 750ml Makeup |
| Input/output | Sensor, Encoder, USB, TCP/IP, optional: 2. Sensor, RS232, traffic light |
| Accessory | Printhead Bracket,stainless steel cabinet, Cleaning kit |
| Approximate weight | 27KG |
| Electrical Requirements | 100 – 240 VAC, 50/60 Hz, Max. Power consumption: 120 W |
| Temperature Range | 5℃ to 45℃ |
| Protection Rating | IP55 |
Our Core Advantages:
20 Years Experience
Support Customization
Customized logo and welcome page are available on most of our machine. We can provide exclusive design for VIP distributors.
Free Sample Printing
We provide free sample marking for customers all over the world. Customers can check the printing quality before order.
Strict quality Control
Each machine is strictly inspected before delivery. We provide at least one year warranty for all of our machines.
Excellent Service Team
Fast Delivery
Typical Applications
Application and Selection Guidance for CM730
For continuous inkjet coding projects, confirm the required code content, production-line speed, substrate, print height, number of lines, installation distance, communication interface and consumable requirements against the verified specifications above. Providing sample images and line information helps INKVEO review the application and recommend an appropriate configuration.
