Product Description
Product Description
High-speed thermal transfer printer (700mm/s) supporting 1D/2D barcodes and TrueType fonts. Features USB/Ethernet connectivity, CoLOS software integration, and robust Industry 4.0 readiness.
Ideal for real-time coding, serialization, and seamless production line control with minimal downtime.
Product Features
High-performance Printing
- Promotional coding function* allows for unique coding on each pack.
- In addition to its dead-dot detection system, the easy-to-install SmartDate Detect-Plus system checks and confirms the code’s presence, position and quality on every pack — directly from the user’s 10.1” interface.
- Print speed: 10 mm to 1800 mm per second, allowing for 455 printed packs per minute at 300 dpi.
Unmatched and Cost-effective Reliability
- Zero preventive maintenance – Robust direct ribbon drive and cassette design contain no wear parts.
- Both intermittent and continuous configurations with a 53 mm printhead are available on the same coder.
- Up to 15% more codes per roll* – Large choice of ribbons based on your packaging type and needs.
- The SmartDate® printheads are certified for 6 months or 40 km as standard.
Enhanced SmartDate Experience
- Coder can be configured to monitor your 5 most important production metrics directly from your home screen (e.g., pack rate, throughput, availability).
- Animated help and “how to” tutorials provide guidance on setup and daily maintenance procedures to ensure consistent print quality.
- Configurable profile password function (operator, supervisor, engineer) manages access and limits human-related errors.
Specification
| Model | Feature | X30 | X45 | X65 |
| Print feacture | Print speed |
Intermittent: 100 to 600 mm/s Continuous: 50 to 600 mm/s |
Intermittent: Up to 600 mm/s Continuous: 10 to 600 mm/s
|
Intermittent: up to 700 mm/s Continuous: 10 to 1800 mm/s |
| Print area |
Intermittent: 32 mm x 40 mm Continuous: 32 mm x 100 mm |
Intermittent: 32 mm or 53 mm x 75mm Continuous: 32 mm or 53 mm x 250mm |
Intermittent: 53 mm x 75mm Continuous: 53mm x 750 mm (combined /application dependent) Continuous: 53 mm x 100mm (shuttled) |
|
| Gap between prints |
0.5 mm |
0.5mm |
0.5MM |
|
| Print features |
– Automatic printhead setup |
– Automatic printhead setup |
-Automatic printhead setupDetect: Dead-dot detection |
|
| Additional print features |
Printing of real-time clock, dates and auto-updating best before dates, barcodes |
Printing of real-time clock, dates and auto-updating best before dates, barcodes |
Printing of real-time clock, dates and auto-updating best before dates, barcodes |
|
| Fonts |
True Type font support, including non-Roman characters and symbols |
True Type font support, including non-Roman characters and symbols |
True Type font support, including non-Roman characters and symbols |
|
| Barcode support |
Han Xin, GS1 standard compliant, DataMatrix, QR and Composite RSS barcodes |
Wide choice of 1D and 2D barcodes: ITF, Code39, Code 128, EAN 128, EAN 8, EAN 13, UPCA, UPCE, RSS linear, PDF 417, GS1 standard compliant, DataMatrix, QR and Composite RSS barcodes support |
Wide choice of 1D and 2D barcodes: ITF, Code39, Code 128, EAN 128, EAN 8, EAN 13, UPCA, UPCE, RSS linear, PDF 417, GS1 standard compliant, DataMatrix, QR and Composite RSS barcodes support |
|
| Consumable Specifications | Thermal transfer ribbons |
Available in a variety of grades and colors |
Available in a variety of grades and colors |
Available in a variety of grades and colors |
| Maximum ribbon length |
Up to 700 m |
Up to 1100m |
Up to 1100m |
|
| Ribbon width |
22 mm and 33 mm |
20-55mm |
20-55mm |
|
| Ribbon save options |
Radial ribbon save mode and interlaced mode |
Radial ribbon save mode and interlaced mode, radial interlaced mode, radialwhitespace mode and step adance mode |
Digital ribbon save(DRS)mode, interlaced mode, radial ribbon save mode,radial interlaced mode, radial whitespace mode, stepadance mode and whitespace mode. |
|
| Recommended ribbon ranges |
Best results with SmartDate® Xceed, SmartDate® Xtra and SmartDate® Xpert ribbon ranges |
Best results with SmartDate® Xceed, SmartDate® Xtra and SmartDate® Xpert ribbon ranges |
Best results with SmartDate® Xceed, SmartDate® Xtra and SmartDate® Xpert ribbon ranges |
|
| Operating Characteristics | User interface |
Optional handheld terminal / remote UI (no built-in screen) |
10.1″ full color 1024×600 touchscreen |
10.1″ full colour 1024 x 600 touchscreen for messageselection, variable data entry, diagnostics and systemsetup |
| Hardware interface |
Inputs: “Print go” and 1 configurable input Outputs: Fault, warning, + 2 configurable outputs
|
Inputs: “Print go” and 1 configurable input Outputs: Fault and warning
|
Inputs: “Print go” and 1 configurable input |
|
| Software interface |
USB for uploading/downloading images, settings, data files; message storage location. |
USB for downloading images, settings and data files. RS232, Ethemnetcommunications standard. Communicationsorotocols for PCs, PLC and packaging machines,ncluding full remote control web server |
USB for downloading images, settings and data files. RS232, Ethemnetcommunications standard. Communicationsorotocols for PCs, PLC and packaging machines,ncluding full remote control web server |
|
| Other |
Parent/Child function to allow control up to 7 printers |
Parent/Child function to allow control up to 7 printers， |
Parent/Child function to allow control up to 7 printers， |
|
| Weight |
Intermittent printer: 5.5 kg |
Printer: 7.8 kg |
Printer: 7.8 kg |
|
| Environment |
Temperature range: 0°C to 40°C |
-Temperature range:0°C to 40°C |
-Temperature range:0°C to 40°C |
|
| Options and Accessories | User interface |
– Optional color remote user interface |
-Detect-Plus: Code detection |
-Detect-Plus: Code detection |
| Accessories |
Mounting bracket, encoders and barcode scanner |
Mounting bracket, encoders, and barcode scanner |
Mounting bracket, encoders, and barcode scanner |
Our Core Advantages:
1.20 Years Experience
Over 20 years of experience In coding and marking Industrial .
We have provided professional solution for customers in different applications all over the world.
2.Support Customization
Customized logo and welcome page are available on most of our machine. We can provide exclusive design for VIP distributors
3.Free Sample Printing
We provide free sample marking for customers all over the world.Customers can check the printing quality before order.
4.Strict quality Control
Each machine is strictly inspected before delivery in.We provide at least one year warranty for all of our machines.
5.Excellent Service Team
Quick and high efficient Response from our professional service team.
Oversea training and installation are available.
6. Fast Delivery
We can handle most orders within 7 days.Safe packing and quick dell very allow distributors to make.
Overseas After-sales Engineer，More than 20 years of Veteran Senior Engineer
Typical Applications
Application and Selection Guidance for Markem Imaje SmartDate TTO X65
For thermal-transfer overprinting projects, confirm the required code content, production-line speed, substrate, print height, number of lines, installation distance, communication interface and consumable requirements against the verified specifications above. Providing sample images and line information helps INKVEO review the application and recommend an appropriate configuration.
